If you’re comfortable with tools and measurements, you’ll probably figure out a few variations along the way. What I’m presenting here is one of many ways a craftsman could achieve a good backcountry ski touring binding mount. Also, IMPORTANT: if you’re new to ski work slow down and do a practice mount on a pair of dumpster skis or a 2×4. The keys to success in home mounting bindings are careful measurement, moving slow, and using the paper template and your boots as a substitute for the mechanical jig used by ski shops.
TYROLIA BINDING INSTRUCTIONS PAPER TEMPLATE DOWNLOAD
That said, starting in late 2012 the Dynafit Radical FT and ST models have brakes that are NOT user removable, other later models also do not have removable brakes.įor easier access to mounting screws, with most tech bindings you can remove the remove the heel housing from the heel plate, though doing so is often not necessary if you have the right tooling (torx 2.0 or posidrive driver, with skinny section about 3 inches long to fit between brake and heel housing.) Warning: These instructions are based on using a paper template you will download and print, please verify scale of printing by comparing template to actual physical binding - before drilling holes in ski. Note that some Dynafit models with brakes, such as Vertical/ST/FT and Radical, may require removal of brakes to facilitate mounting. For ease of mounting the Radical FT, we’d recommend not worrying about the stiffening plate, simply leave it off - chuck it in the trash or hang as a mirror medallion in your Sprinter van.
We’ve tested and skied this binding and felt no difference with the stiffening switched on or off (or removed entirely). (Be aware that in the case of Dynafit Radical FT 12 the distance between toe and heel has to be perfectly set for the binding’s “stiffening plate” to function as designed. If you have questions or observations, please bring them up as a comment on this post. We provide no obligatory support or help with using these instructions - you are on your own. Disclaimer: By using these mounting instructions and templates, you agree to not hold, its owners or associates liable for anything. Novices, don’t skip any steps! Instructions below picture an early Dynafit binding model, but work for most other models (check hole patterns by setting binding on paper template, some early bindings have heel unit hole patterns that may be slightly different.). If you have a modicum of experience, you’ll find some of the steps to be redundant or easily shortcut. I’ve not found a way to make it simpler without introducing possible errors that novices could make. I know the process I outline is a bit complicated. Once every few years we re-pub with a current date so it’s clear that we keep it as current as possible This time we have the support of helping to keep it going. I’ve worked on this post constantly since it was published some time ago.
TYROLIA BINDING INSTRUCTIONS PAPER TEMPLATE INSTALL
Homebrew DIY backcountry ski touring binding install tricks and tips, mount them yourself! We are extremely excited to announce that Binding Freedom is part of the Sun.ĭynafit bindings, you can mount them yourself, but do it carefully. (You can find instructions to do that here).
